GODO GD-H2 Heavy Lift UAV
- design for delivery
GD-H2 is equipped with eight powerful motors to provide strong power. It has upto 20kg loading capacity, which is suitable for operation tasks with heavy and diversified load. The enclosed engine room with high-strength 3K carbon fiber is characterized by high temperature resistance, corrosion resistance, rain resistance, dust prevention, creep resistance, etc., which can effectively protect internal electronic components. It adopts modularized design, 20s rapid replacement of various professional mounting equipment, to achieve rich functional expansion, meeting the professional needs of various industrial scenarios.
Key features
3K Carbonfiber Fuselage
20kg-loading Capability
8 Powerful Motors
Quick-detachable Tripod
Large Capacity Batteries
High Reliability Design
Industrial Grade Protection
Airtight & Heat-resistant Design
Specification
| GD-H2 UAV |
Fuselage material |
3K carbon fiber |
| wheel base |
1350mm |
| Unfold size |
1196*1257*1160mm (Excluding blades) |
| Fold size |
555*872*210mm (Excluding blades) |
| Maximum takeoff weight |
42kg |
| Maximum load |
20kg |
| Maximum endurance time without load |
40min |
| 10kg load endurance |
15min |
| Maximum takeoff altitude |
3000m |
| Maximum wind resistance |
10m/s |
| Hover accuracy |
≤0.5m |
| Maximum working radius |
10km |
Applications
Small parcel delivery
Emergent supplies delivery
Medical supplies delivery
Product advantages
1),Easy to operate
2),Automatic flight
3),Low battery/runaway protection
4),20 kg ultra-large delivery
5),Embracing & foldable arms
6),Industrial grade tri-proofing capability
7),Quick detachable mounting and tripod
